Key Features
-
High Current Capacity 120A continuous per motor pad (480A total)
-
Wide Voltage Range 3-8S LiPo (11.1V 33.6V) compatible
-
Standard Mounting 30.530.5mm hole pattern for stack integration
-
Separate ESC Design Ideal for builds with individual ESCs
-
Ultra-Lightweight Only 13.5g minimizes weight impact
-
Compact Form Factor 44.5436.3mm fits tight frames
Technical Specifications
-
Model: PDB-4
-
Input Voltage: 3-8S LiPo (11.1V 33.6V)
-
Max Current: 120A per motor pad
-
Mounting Pattern: 30.530.5mm
-
Dimensions: 44.5436.3mm
-
Weight: 13.5g
-
Configuration: For separate ESCs (4-in-1 ESC not required)
Technical Specs of 80A ESC
- Input Voltage:2-8S LiPo (8.4V-33.6V)
- Dimensions:42.520.58.5mm (fits 2020 & 3030 mounts)
- BEC:OPTO
- Weight:25g (without wires)
Wiring & Connections
-
Main Power Input: Large solder pads for battery leads
-
4 Motor Outputs: Dedicated pads for each ESC
-
Ground Loop Prevention: Optimized layout minimizes noise
Applications
-
FPV Racing Drones 3-5″ builds with separate ESCs
-
Freestyle Quadcopters Reliable power distribution for aggressive flying
-
Cinewhoops & Long-Range Clean power distribution
-
Custom Drone Builds Flexibility for various ESC configurations
